Multi V Dies for Flexible Press Brake Bending
Explore our press brake tooling products engineered for varied sheet metal gauges. Minimize costly setup times, streamline job switching, and maintain precise bending accuracy across high-mix production runs.
- Multi-Opening Versatility
- Rapid Tool Indexing
- Precision CNC Ground
- Custom Geometry & Lengths
Tooling Design Feature
Precision Ground Multi-V Openings & Deep Hardened Working Surfaces
What Are Multi V Dies?
Multi V dies integrate multiple V-grooves into a single block, allowing press brake operators to quickly adapt to different material thicknesses and bend radii without changing out the lower tool. For a broader look at our products, this tooling style is built for fast changeovers and flexible production.
Versatile V Opening Tooling
Multiple precision-milled openings on one body broaden your press brake die openings range for seamless multi-gauge bending.
Efficient Working Principle
Simply rotate the die to access a different opening size, dramatically reducing non-productive setup and changeover time.
Multi V vs. Standard Single V Dies
Standard single V dies require full tool teardowns whenever sheet metal gauges change. By consolidating several openings into one durable tool block, multi V dies offer superior bending compatibility—making them ideal for high-mix, low-volume job shops and fast-paced production lines. They also fit naturally into a broader press-brake-tooling strategy when consistency and speed matter most.
CAMT leverages decades of tooling manufacturing experience to help shop managers evaluate die geometry and select the right multi-groove configuration and matching press-brake-punches for their bending requirements.
Tooling Structural Comparison
Core Advantages & Business Value of Multi V Dies
Maximize shop-floor throughput, reduce tooling overhead, and maintain consistent bending precision across all sheet metal production runs. Explore our products to find the right fit for your fabrication workflow.
One Die, Many Uses
Multiple integrated V-openings consolidate versatility, lowering tool inventory costs and dramatically reducing setup changes while supporting flexible press brake tooling setups.
Higher Line Efficiency
Streamlines high-frequency job switching, minimizing machine downtime and keeping production schedules on track.
Broad Material Compatibility
Handles mild carbon steel, stainless steel, and aluminum sheets with equal precision across various bend radii.
Stable Precision Ground Dies
Precision grinding and controlled heat treatment maintain tight angular tolerances and exceptional long-term accuracy.
Fully Customizable
Engineered around your material thickness range, press brake tonnage, and specific production cycle targets. Learn more about our press brake punches for matched tooling performance.
Easy to Maintain
Machined from high-hardness tool steel for durability, easier shop-floor management, and standard maintenance.
Built for High-Mix, High-Volume Fabrication
CAMT enhances Multi V die stability in batch production through precision grinding, specialized heat treatment, and CNC machining—delivering reliable, durable press brake dies and press brake tooling for demanding manufacturing environments.
Technical Specifications & Structural Parameters
Evaluate exact press brake die specifications, load tolerances, and material grades. CAMT customizes multi V dies tailored to your press brake tonnage and production requirements, with a broader press brake tooling range available for matched setups.
Standard Multi V Die Parameters
ISO / CNC Standard| Parameter Field | Standard Range | Custom Capability |
|---|---|---|
| Overall Die Length | 835 mm / 415 mm segmented | Up to 6,000 mm continuous or custom segments |
| Number of V-Openings | Multi-V (4-Way / 2-Way) | Custom die opening configurations & spacing |
| Die Opening Range | V6 mm – V120 mm | V4 mm – V300+ mm engineered profiles |
| Compatible Sheet Thickness | 0.5 mm – 16.0 mm sheet metal | Heavy plate options up to 32 mm |
| Available Tonnage | 100 Ton/m – 400 Ton/m max load | Reinforced high-tonnage die blocks |
| Material Grade | 42CrMo / Cr12MoV tool steel | Premium alloy tool steel press brake tooling |
| Hardness Range | HRC 47 ± 3 (Working surface) | Deep laser induction hardening on V-grooves |
| Surface Precision | ±0.01 mm precision ground finish | Non-marking inserts & special surface coatings |
| Machine Interface | European / Amada / Trumpf style | Custom tangs, adapters & bed compatibility |
835 mm / 415 mm (Segmented)
Custom: Up to 6,000 mm continuous length
Multi-V (V6 mm – V120 mm)
Custom V-opening combinations & angles
0.5 mm – 16.0 mm | 100–400 Ton/m
Heavy plate support up to 32 mm thickness
42CrMo Tool Steel | HRC 47 ± 3
Vacuum heat treatment & laser hardening
±0.01 mm | European, Amada & Trumpf
CNC machined dies with universal adapters
Engineering Spec Sheet
Save and share these structural parameters with your process planning team.
Multi V Opening & Structural Logic
Multi V dies integrate multiple V-grooves on a single block, eliminating frequent die changes. Simply rotate the die body to match various sheet thicknesses, while sectional designs allow easy single-piece replacement.
Tool Steel Heat Treatment & Precision Grinding
Machined from high-hardness 42CrMo/Cr12MoV tool steel, each die undergoes CNC milling, vacuum heat treatment, and precision surface grinding to ensure exceptional wear resistance and bend consistency.
Press Brake Compatibility
Engineered to interface seamlessly with major CNC press brakes, including European, Amada, Trumpf, and LVD styles. Compatible with standard mechanical, hydraulic, and pneumatic clamping systems, plus matched press brake punches for complete forming setups.
Custom Tooling Capabilities
CAMT customizes multi V dies to match your press brake tonnage, sheet metal specifications, and cycle times, speeding up selection and line setup. For clearance-critical forms, we can pair the setup with offset punches and other specialized profiles.
Need Custom Tooling Specifications?
Our engineering team evaluates your press brake die specifications, load tolerances, and clamping dimensions prior to production. Send us your sheet thickness and machine details for CAD verification and precise tooling recommendations.
Supported files: STEP, IGES, DXF, DWG, PDF
Press Brake Tooling Buying Guide
How to Choose the Right Multi V Dies
Follow this 5-step selection guide to match the ideal multi V die configuration to your material thickness, bend geometry, and press brake specifications, and compare it with the right press brake tooling for your workflow.
Confirm Sheet Thickness Range
Map out your primary sheet metal gauges. Ensure the combined V-opening dimensions seamlessly cover your full range of production thicknesses without requiring secondary tooling setups.
Analyze Material Properties
Account for tensile strength variations across carbon steel, stainless steel, and aluminum. Matching material properties to correct V-widths prevents machine overloading and sheet surface marking.
Verify Bend Angles & Radius Needs
Determine required bend angles and inside radii. Broader or specialized V-groove geometries may be necessary to compensate for material springback or tight tolerance demands, especially when gooseneck punches are needed for part clearance.
Check Machine Tonnage & Bed Compatibility
Confirm your CNC press brake tonnage ratings, table length, and clamping tang interface to guarantee exact mechanical compatibility and safe operation, particularly when pairing the die with offset punches.
Evaluate Production Cycle Times
High-mix, low-volume job shops benefit significantly from multi V dies to minimize changeover downtime, whereas continuous single-spec runs may suit dedicated single-V dies.
Need Expert Tooling Selection Help?
Send us your plate thickness, material grade, and machine model. CAMT application engineers will evaluate your parameters and recommend the optimal multi V die configuration.
Request Tooling Recommendation
Die Selection Matrix
| Evaluation Criteria | Multi-Variety Flexible Line | Single Standardized Process |
|---|---|---|
| Thickness Coverage | Wide range (multiple V openings) | Fixed gauge focus |
| Setup & Changeover | Instant rotation, zero tool swaps | Infrequent tool changes |
| Tooling Recommendation | Precision Multi V Die Set | Dedicated Single-V Die |
| Storage & Inventory | Consolidated into fewer dies | Requires multiple separate dies |
| First-Part Accuracy | High via CAMT precision grinding | High for repetitive runs |
| Ideal Environment | Contract fabricators & job shops | High-volume OEM production |
* CAMT provides tailored tooling engineering support based on your component drawings, sheet metal specs, and press brake parameters.
Custom Manufacturing and Quality Assurance
CAMT integrates OEM/ODM tooling development with end-to-end quality control, delivering high-precision press brake tooling and Multi V dies built for long-term durability and demanding production lines.
OEM Press Brake Tooling & ODM Capabilities
We translate complex sheet metal bending requirements into durable, high-performance tooling through precision engineering and structural optimization, including press brake punches for matched setup compatibility.
Drawing-Based Processing
Full-scale precision manufacturing executed directly from customer blueprints or CAD files.
Structural Optimization
Refining die geometries and V-opening layouts to improve load distribution and extend service life.
Batch Production
High-capacity volume manufacturing with strict repeatable accuracy for multi-machine setups.
Technical Support for Bending
Expert engineering consultations to evaluate springback, tonnage limits, and material compatibility.
Quality Assurance & Inspection Protocol
Every Multi V die undergoes rigorous verification checkpoints to ensure consistent precision, high wear resistance, and operational safety.
Raw Material Selection
Sourcing premium tool steel with full mill test certificates and chemical composition verification.
Controlled Heat Treatment
Deep hardening processes ensure uniform core strength, elevated surface hardness, and crack prevention.
Precision CNC Grinding
High-precision surface grinding maintains exact V-groove radii, side angles, and micro-finish tolerances.
CMM Dimensional Inspection
100% coordinate measurement verification across critical V-openings, pitch centers, and mounting surfaces.
Trial Assembly & Fit Checks
Simulated press brake seating and alignment checks guarantee seamless installation upon delivery.
CAMT guarantees stable, long-term performance—eliminating batch variance and preventing premature tool wear on high-tonnage production lines, with compatible offset punches available for clearance-sensitive forming applications.
Fast Prototyping
Rapid turnaround for custom Multi V die prototypes to accelerate testing and approval cycles.
Stable Batch Supply
Structured inventory scheduling and predictable lead times support uninterrupted continuous manufacturing.
Global Export Logistics
Heavy-duty anti-rust packaging and full export documentation for secure, timely worldwide delivery.
Frequently Asked Questions About Multi V Dies
Find clear answers regarding multi V dies selection, sheet metal thickness compatibility, custom tooling lead times, and press brake tooling integration.
What sheet thickness range is suitable for Multi V Dies?
Multi V Dies typically handle sheet thicknesses from 0.5 mm up to 20 mm or more, depending on the block size and V-opening configuration. Operators simply index or rotate the die block to transition seamlessly between thin sheet fabrication and heavy plate bending without changing out the lower tool.
Contact CAMT technical support to confirm the exact V-opening layout for your specific material gauges.
What are the advantages of Multi V Dies compared with standard V dies?
Multi V Dies integrate several groove sizes into a single body, eliminating frequent teardowns when switching jobs. This design drastically reduces machine setup downtime, lowers floor storage footprint, and enhances bending efficiency for high-mix, small-batch manufacturing.
Reach out to our engineering team to evaluate cycle time savings and ROI for your shop floor.
Can dimensions and opening combinations be customized from drawings?
Yes. We manufacture custom length profiles, specialized V-angles, custom shoulder radii, and target opening sequences. CAMT engineers tailor tooling geometries directly from your CAD drawings or part prints to ensure optimal bend accuracy and clearance.
Submit your CAD files or technical specs to CAMT for a prompt custom design proposal.
Which press brake tonnage and machine interfaces are supported?
Our multi V dies support light-duty electric presses as well as heavy hydraulic machines exceeding 1,000 tons. We supply mounting bases, alignment tangs, and adapters compatible with European Precision, Trumpf-Wila, American Traditional, and specialized CNC clamping systems, plus gooseneck punches for deeper bend access.
Share your machine model and bed dimensions with us to confirm precise interface fitment.
How can I tell whether my production line needs a Multi V Die?
If your facility routinely bends multiple sheet gauges, suffers from excessive tooling setup bottlenecks, or seeks to streamline die inventory, multi V tooling is a highly effective choice. It offers maximum flexibility for job shops handling diverse enclosure, cabinet, or structural components.
Consult with a CAMT application specialist to assess your current product mix and tooling requirements.
How are lead time and minimum order quantity handled?
Standard multi V dies typically ship within 3 to 7 business days from stock. Custom tooling projects generally require 2 to 4 weeks depending on steel grade, heat treatment depth, and profile complexity. CAMT supports flexible ordering with low MOQs (starting at 1 set/piece) for global clients.
Contact our sales team today to check current stock levels or schedule custom production delivery.
Need Help Selecting the Right Press Brake Tooling?
CAMT provides tooling compatibility checks, custom drawing reviews, and technical recommendations for press brake punches, dies, and custom bending solutions.
Tell Us Your Bending Requirements
Send your sheet thickness, material specifications, machine model, and target bend profiles. CAMT engineers will recommend the optimal Multi V die configuration for your production requirements.
Why Partner With CAMT
Custom Engineering
Custom die solutions based on drawings and machine specifications.
Technical Guidance
Professional support for die opening selection and tooling matching.
Global Supply
Reliable OEM manufacturing and worldwide delivery support.
CAMT delivers precision Multi V die solutions that reduce setup time and improve bending consistency for fabricators worldwide.
Ready to Select the Right Multi V Die?
Share your machine details and bending requirements. Our engineers will review your application and provide the right tooling recommendation.
Technical review and quotation support within 24 hours
